In the quest for sustainable solutions to manage the environmental impact of desalination, a team of researchers led by Marwa Magdy from the Egypt Desalination Research Center of Excellence (EDRC) and Ain Shams University has made a significant breakthrough. Their work, published in the journal ‘Desalination and Water Treatment’ (translated to ‘Treatment and Purification of Water’ in English), introduces an innovative method for treating reverse osmosis (RO) desalination brine while simultaneously producing valuable acids and bases.
Reverse osmosis desalination is a critical process for providing fresh water in arid regions, but it generates a highly saline brine that poses environmental challenges. Magdy and her team have developed high-performance cation exchange membranes (CEMs) and bipolar membranes (BPMs) that address these concerns through a process called electrodialysis with bipolar membranes (EDBM).
The researchers created the CEM by blending polyvinyl alcohol (PVA) with carboxymethyl cellulose (CMC) and incorporated it into a BPM structure with a chitosan-based Anion Exchange Layer (AEL). This novel approach was rigorously tested and characterized, demonstrating significant improvements in material properties.
One of the key innovations in this study was the pre-treatment of the membranes with ferric chloride (FeCl3) before sulfonation using sulfuric acid. This step boosted the Ion Exchange Capacity (IEC) from 0.317 to 0.53 meq/g, outperforming the commercial standard Nafion-117. “This enhancement in IEC is a game-changer,” Magdy explained. “It allows our membranes to achieve superior performance in salt rejection and energy efficiency.”
The system achieved a salt rejection rate of 55.2%, with acid and base concentrations increasing by factors of 19.2 and 9.04, respectively. Additionally, the system exhibited a low voltage drop of 2.16 V at 90 mA/cm², outperforming previously reported BPM-1 (3.45 V) and BPM-60 (2.73 V). These results highlight the membrane’s enhanced energy efficiency and potential as a cost-effective solution for sustainable brine management.
The commercial implications of this research are substantial. The energy sector, which is increasingly focused on sustainability, could benefit greatly from this technology. By treating RO brine effectively and producing valuable acids and bases simultaneously, this method could reduce the environmental footprint of desalination plants and create additional revenue streams.
“This research opens up new possibilities for the energy and water sectors,” Magdy noted. “The ability to treat brine efficiently while generating useful by-products is a significant step towards more sustainable and economically viable desalination processes.”
The study’s findings suggest that this innovative membrane technology could shape future developments in the field of water treatment and desalination. As the demand for fresh water continues to grow, especially in water-scarce regions, the need for sustainable and efficient desalination technologies becomes ever more critical. This research provides a promising avenue for addressing these challenges while also contributing to the circular economy by converting waste into valuable products.
In summary, Magdy and her team have developed a groundbreaking method for treating RO desalination brine that not only addresses environmental concerns but also offers economic benefits. Their work, published in ‘Desalination and Water Treatment’, represents a significant advancement in the field of water treatment and holds great promise for the future of sustainable desalination.
